■ Product Overview
With increasingly stringent industry regulations, metal foreign object detection has become an indispensable part of capsule production lines.100% Capsule Tablet Metal Detector, as highly sensitive testing equipment specifically designed for finished or semi-finished capsules, effectively ensure the purity and safety of pharmaceuticals and are widely used in the pharmaceutical, health product, and food additive industries.
■ Tech Specifications
Type:SG-M50
Inlet height: 770-930mm Port size: 76mm
Outlet Height: 770-860mm Port size: 51mm
Effective passing size: W70*H20mm
Maximum production capacity: 500,000 pcs/hour
Sensitivity(adjustable or not):Yes
Detection sensitivity: Fe: 0.3mm, SUS: 0.5mm,Non-Fe:0.5mm
Operation Mode:Touch Screen/LED fast key input
Machine weight: 65kg
Removal method: flip culling
Working voltage: 220V/110V, 50/60HZ
■ Main Features
1. High-Sensitivity Metal Detection
Utilizing electromagnetic induction technology, this system can accurately detect minute metallic foreign objects, including iron (Fe), stainless steel (SUS304/316), and non-ferrous metals (copper, aluminum, etc.), inside and outside capsules. Sensitivity reaches 0.3–0.5 mm (depending on the model).
2. High-Speed Inline Screening
Seamlessly integrated with pharmaceutical production lines, it can continuously detect metal foreign objects during the high-speed descent of capsules without affecting production rhythm, achieving 100% inspection.
3. Auto Reject Mechanism
Once a capsule containing metal is detected, the machine automatically rejects it using a flip-plate, ensuring drug safety.
4. Pharma-Dedicated Channel Design
Equipped with a narrow channel and smooth guide rails, it avoids jamming and dust accumulation; capsules pass through quickly and with high stability.
5. Digital Signal Processing Technology
Reduces noise interference, improves signal stability, and maintains high detection accuracy even under high-speed conditions.
■ Application
■ Customers
■ Exhibitions
■ Packaging & Delivery
Our machines is fully tested and calibrated before delivery.
It is packed in a strong wooden case with internal shockproof protection.
Various shipping options are available — by sea, air, or land — ensuring safe and on-time delivery by professional logistics partners.
