■ Product Introduction
Tablet Capsule Metal Detector, easy to adapt to the site, intuitive access, convenient experience operation, compact overall structure, closed conveying channel, acceptable toxic production process, harmless to human body, ensuring drug safety and hygiene. This product is available in all types of tablets. Pharmaceutical Automatic Metal Detector can be matched with any type of tablet pressing machine.
■ Tech Specifications
Type:SG-M50
Inlet height: 770-930mm Port size: 76mm
Outlet Height: 770-860mm Port size: 51mm
Effective passing size: W70*H20mm
Maximum production capacity: 500,000 pcs/hour
Sensitivity(adjustable or not):Yes
Detection sensitivity: Fe: 0.3mm, stainless steel: 0.5mm
Machine weight: 65kg
Removal method: flip culling
Working voltage: 220V/110V, 50/60HZ
■ Main Features
1. Suitable for detecting magnetic and non-magnetic metal foreign objects in separated capsules or tablets.
2. Product tracking function: It can automatically make internal adjustment compensation according to the change of product effect.
3. Using the latest micro-processing control system, it has the function of automatic learning and setting.
4. The metal detection coil is made of stainless steel, and the inside is completely sealed, with stable performance.
5.5 seconds disassembly, easy and convenient, no need to use any tools.
6. The equipment has the advantages of low noise, convenient disassembly and assembly, easy cleaning, beautiful appearance, etc.
7. The internal and external structures are treated with stainless steel mirror surface, the appearance is beautiful and generous, and the interior is easy to clean.
8. Imported driving device, the equipment runs silently and stably, and is equipped with lockable casters for easy movement.
9. The metal parts in contact with the tablets are all made of food-grade materials, which meet the requirements of GMP.
■ Application
■ Customers
■ Exhibitions
■ Packaging & Delivery
Inner use the plastic wrapping ,out package will use stronger wooden cases.
Our standard package process:
1) Dust & Cleaning
2) Lubricate Drive Parts
3) Divide Machine Into Modules
4) Wrap Modules With Plastic Film
5) Packing Modules into Plywood Cases
6) Mark Shipping Mark In The Cases
If any special requirements, we will pack it as requested.
