■ Product Brief
Inclined Conveyor Metal Detector for Bags is an automatic inspection solution designed for detecting metal contaminants in bagged and flexible packaged products. Its inclined conveyor structure provides both product elevation and online metal detection, making it suitable for production lines where floor space or conveyor height is limited.
The system can be customized according to inclination angle, conveyor length, belt width, detection aperture, line height and reject method. This makes it suitable for snack bags, frozen foods, rice, flour, coffee, pet food, spices, powders, granules and other packaged products.
■ Technical Data
| Name | Inclined Conveyor Metal Detector |
| Detection sensitivity | Fe≥Φ0.5mm, Non-Fe≥Φ0.5mm, SUS≥Φ0.8mm |
| Conveyor Type | Inclined Belt Conveyor |
| Inclination Angle | 15°–45° (Customizable) |
| Detecting Width | 150-1000mm(Customizable) |
| Belt Height | Customized |
| Belt Speed | 25m /min (or specified) |
| Reject System | Alarm & Stop / Air Blast / Pusher / Flipper / Retracting Belt (Optional) |
| Protection Rating | IP65 |
| Power Supply | AC 220V ±10%, 50/60Hz (110V Optional) |
■ Product Highlights
1.Metal Contaminant Detection
Detects ferrous, non-ferrous and stainless-steel contaminants in packaged products.
2.Inclined Product Conveying
Combines product transportation and metal inspection, helping overcome height differences between production-line sections.
3.Customizable Inclination Angle
The conveyor angle, height and length can be customized according to the customer’s production-line layout.
4.Automatic Reject System
Automatically removes contaminated products through pneumatic reject, flap reject, pusher or belt-stop systems.
5.High-Sensitivity Detection
Digital signal processing and product learning help maintain stable detection performance across different products and packaging formats.
6.Stainless Steel Construction
Hygienic stainless-steel construction is suitable for food processing and packaging environments.
7.Flexible Line Integration
Can be integrated with existing conveyors, packaging machines and other inspection equipment.
8.Space-Saving Design
The inclined conveyor allows products to move between different production-line heights without requiring a long horizontal conveyor.
■ Industry Applications
■ Company Profile
■ Cooperative Clients
■ Exhibition
■ Package & Logistics
● Our machines undergo comprehensive testing and commissioning before shipment to ensure stable and reliable performance.
● Equipment is packaged in thickened wooden crates with shock and moisture-proof interiors to effectively prevent damage during transportation.
● We partner with several professional international logistics companies and support a variety of shipping methods, including sea, air, and land transport.
● Ensure the equipment arrives safely and on time at your facility.
